System Anl 3
Default setting
Co1 -> Fb00 = OFF (without RF1)*
Co1 -> Fb01 = OFF (without RüF1)
Co1 -> Fb02 = ON (with AF1)
Co2 -> Fb00 = OFF (without RF2)*
Co2 -> Fb01 = OFF (without RüF2)
Co2 -> Fb02 = OFF (without AF2)
Co5 -> Fb00 = ON (with VFsek)
Co5 -> Fb01 = ON (with RüFprim)
* Only for optimization and temperature reading
EB 5179 EN
31
Systems
BE
BA
AE
RK
AF2 AF1
RüF
prim
VF
sek
UP1 UP2
RK
HK1
RK
FW
RF1 VF1
RüF1 RK
HK2
RüF2
RF2 UP3
VF2 VF3
