Miscellaneous Information : Connecting To Other Devices
Connecting to a VCR
You can connect your Miniket Photo to a TV set through a VCR.
1. Connect the provided Audio/Video Cable to the [Earphones and AV jack] of the Miniket Photo.
2. Connect the other end of the cable to the VCR
set by matching the colours of the terminals.
3. Connect the Audio/Video Cable from TV Input
to Video Output.
4. Turn on the TV and set the to the
external input source.
5. Turn on the VCR and set the to the
external input source where you connected the
Miniket Photo.
[ Notes ]
✤ You can play back photo files as well as the movie files.
✤ When connected to other devices with the Audio/Video cable, no screen is displayed on the LCD monitor.
Line Input
Line Output
Line Input
VIDEO AUDIO
(L) (R)
