Specifications
System Information
Processor Intel PXA263 CPU at 400MHz
Memory - ROM : 64 MB
- RAM : 128 MB
Operating System Windows Mobile TM 2003 second
edition software
Display
LCD Type 3.5" transflective TFT-LCD
with back-light LEDs,
touch-sensitive screen
Resolution 240 x 320 at 65,536 colors
GSM/GPRS (Quad-band) Module
GSM 850 824-849, 869-894 MHz
GSM 900 880 ~ 915, 925 ~960 MHz
GSM1800 1710 ~ 1785, 1805 ~ 1880 MHz
GSM1900 1850 ~ 1910, 1930 ~ 1990 MHz
Internal antenna Yes
Physical
Dimensions 71.6 mm (w) x 125 mm (h) x 18.7 mm (l)
Weight 190g
Expansion Slots
SDIO/MMC Yes
supports
Controls and Lights
Navigation 5-way navigation pad
Buttons - 8 program buttons :
Calendar,Contacts,
Multimedia, Record,
Start, Messaging, Internet
Explorer, OK.
- 2 phone function : Call,End
- Volume control button (Up/
Down)
- Power on/off
- Reset button
LED Lights 1 - Event notification
(on the right) - Charge status
- GSM/GPRS signals
LED Lights 2 - Bluetooth system
notification
(on the left) - WiFi system notification
Audio
Audio controller AGC
Microphone/ Built-in
Speaker
Headphone
WAV/WMA/AMR/MAR-WB/
AAC/AAC+/MP3 stereo
Connection
Infrared SIR
I/O port 22-pin individual port for
signals (for USB, Serial, and
power)
Audio Stereo headphone jack
(2.5Ø)
Bluetooth 1.1 compliant, power class 2
WiFi IEEE 802.11b compliant
Power Supply
Battery 1490mAh (typical) Lithium
Polymer removable,
rechargeable battery
AC adapter AC input/Frequency :100-140
VAC, 50-60 Hz, Rated Output:
5 VDC, 2A
