Siemens SX66 - Manual (Page 117)

SX66 Phone User Manual 116 SX66 Phone User Manual 117
Settings on your PC
Contact your ISP to get the APN (Access Point Name) . Before you start using your Wire-
less Modem with a serial port or IrDA connection, you need to create a new modem on
your PC first:
1. Click Start > Settings > Control Panel > Phone and Modem Options .
2. Add a new modem by selecting the Modem tab.
3. Enable the checkbox Don't detect my modem; I will select it from a list .
4. Select Standard Modem Types in the Manufacturers field, select Standard 33600 bps
Modem , then select Next .
5. Select your modem port and click Next .
6. When a Modem installation is finished! screen appears, click Finish to go back to the
Modem tab mentioned in Step 2 . Now you can see a Standard 33600 bps Modem in the
modem list.
7. Highlight the modem you just created, click the Properties button, and select the Advanced
tab.
8. Enter the complete string in the Extra initialization commands: field: AT+CGDCONT=1
,"IP","APN","",0,0 .
9. Remember to click the Change Default Preferences button after entering the required
string as mentioned above.
10.Click the General tab and set the Flow Control by selecting None from the drop-down
list. Keep pressing OK until the modem installation wizard exits.
A new standard modem is now set up successfully on your PC, but you still need to create
a new dial-up connection:
1. Click Start > Settings > Control Panel > Network and Dial-up Connections > Make
New Connection .
2. To continue, tap Next .
3. Select Dial-up to the Internet . Tap Next .
4. Enable the option I want to set up my Internet connection manually , or I want to connect
through a local area network (LAN) button, and Next .
5. Select I connect through a phone line and a modem option, and then Next .
6. Enable the Use area code and dialing rules checkbox and enter the telephone number
*99# , and then Next .
7. Enter the username and password you use to log on to your ISP, and then click Next .
8. Enter a name for this connection, and then Next .
9. Select No when the installation wizard asks you to set up an Internet mail account , and
then click Next .
10. After the installation is completed, click Finish .
