Spectrum Brands 72A-196BAREM Series - Manual (Page 3)

Installation and Operation Manual
Date: 6/02/2008 3
27-0027-0111
SCI P/N: 72A-196BAREM Series
72A-190BQREM Series
Introduction & Safety Information
The Spectrum Control PDU is an AC power distribution unit designed to
distribute power for up to eighteen (18) AC loads. The PDU distributes 3
phase power to six individual, over current protected, output banks. The
unit has multiple alarm capabilities and includes an audible alarm circuit.
Voltage and current are monitored and displayed locally on a liquid crys-
tal display and remotely through a LAN connection. Operation/control is
accomplished by use of 16A breaker actuators.
This product complies with FCC, CE, TUV, UL60950-1 and IEC60950
requirements.
Introduction
LCD – Liquid Crystal Display
LED – Light Emitting Diode
LL – Lower Limit
PDU – Power Distribution Unit.
BANK – Any power source entering a PDU that is then distributed to an
output.
UL – Upper Limit
Related Terms
This installation and operation manual contains information about the
Power Distribution Unit and basic installation instructions. The person
installing or integrating the PDU into an electronic system must be sup-
plied with this manual and read it to become familiar with the installation
precautions. Spectrum Control, Inc. cannot be held liable for any dam-
age to persons or property if the safety information in the installation and
operation manual is not followed.
If the safety information is not observed, personnel could be put at risk.
Only authorized personnel who have been properly trained may operate
the device. There are no user serviceable parts inside. Therefore, any
modifications made to the unit by any organization or persons other than
the factory are not permitted.
The general regulations governing the use of electricity in the country in
which the device or integrated system is installed must be observed.
Safety Information
Manual Conventions
Symbol Action Example
< > Click on the items contained within these symbols
with your mouse.
[ ] Press all keys that are contained within these brack-
ets.
[Ctrl]
“ ” Type all characters that are placed between quota-
tions
“1234”
The following actions should be taken when these symbols are present in
various instructions throughout the manual:
