Installation and Operation Manual
Date: 6/02/2008 15
27-0027-0111
SCI P/N: 72A-196BAREM Series
72A-190BQREM Series
Operational Control of PDU
PEAKS - MAX, MIN, RESET
Selecting PEAKS in the menu system allows the user to view the
maximum and minimum values that have been recorded for both voltage
and current for each distribution bank. This feature also gives the user
the option to reset these values.
LIMITS - MAX, MIN
Selecting LIMITS in the menu system allows the user to set the desired
maximum and minimum values to monitor for each bank. These values
will be used by the unit as comparison limits while monitoring bank
voltage and current levels. Decisions concerning minor and major
alarms will be based on this comparison.
CONFIG - DISPLAY MODE
While in Monitor Mode, the unit can display the incoming voltage and
current readings. The menu system allows the user to select one of
three display modes: CYCLE, FIXED, and BAR.
Selecting CYCLE causes the system to cycle the display of channel
measurements. Measurements will be shown in order of voltage
channels and then current banks.
Selecting FIXED turns off the measurement display cycle. Pressing the
LEFT or RIGHT menu buttons while in FIXED mode moves to the next
reading in the cycle list.
In BAR mode, a bar graph is displayed to show all measured bank
currents at the same time. The values are displayed on a 30 amp scale.
Minimum Current Channel A
Maximum Current Channel A
Minimum Current Channel B
Maximum Current Channel B
Minimum Current Channel C
Maximum Current Channel C
Minimum Current All Channel Total
Maximum Current All Channel Total
Minimum Voltage Channel A
Maximum Voltage Channel A
Minimum Voltage Channel B
Maximum Voltage Channel B
Minimum Voltage Channel C
Maximum Voltage Channel C
Reset All Peaks
Minimum Current Channel A
Maximum Current Channel A
Minimum Current Channel B
Maximum Current Channel B
Minimum Current Channel C
Maximum Current Channel C
Minimum Current All Channel Total
Maximum Current All Channel Total
Minimum Voltage Channel A
Maximum Voltage Channel A
Minimum Voltage Channel B
Maximum Voltage Channel B
Minimum Voltage Channel C
Maximum Voltage Channel C
Monitor Display Mode
Display Cycle time
Voltage Calibration Step 1 Chan A
Voltage Calibration Step 2 Chan A
Voltage Calibration Step 1 Chan B
Voltage Calibration Step 2 Chan B
Voltage Calibration Step 1 Chan C
Voltage Calibration Step 2 Chan C
Current Calibration Step 1 Chan A
Current Calibration Step 2 Chan A
Current Calibration Step 1 Chan B
Current Calibration Step 2 Chan B
Current Calibration Step 1 Chan C
Current Calibration Step 2 Chan C
Number of Channels
Contrast
Software Rev
Menu Tree
Alarm Acknowledgment Incoming Power Peaks Incoming Power Limits System Configuration
