M
ODELS
60-1
AND
F60-1
I TEM P ART N AME P ART N O .
A Heating Element 1500W 120 Volt (incl. mounting hardware) 000-0430-055
B Safety Float 000-0814-132
C Water Supply Float Valve 000-1731-012
D Stainless Steel Float A00-1309-012
E Transformer 120 Volt to 24 Volt 000-0814-133
F Humidifier Control Relay 000-0431-031
G 6-pc. Gasket Set (includes hose cap washer) A00-0693-020
H Thermal Fan Control Switch 000-0431-030
I Operation Indicator Light 000-0814-139
J S-Cleat “Mounting Strips” (set of 3 pcs.) A00-1707-078
K Humidistat Assembly SK0-0055-001 or
SEH-7100-000
28
CONTRACT
OR
Replacement Parts
Contractors: Parts may be ordered through your preferred heating or
plumbing distributor. When ordering, refer to the parts list below to give
the following information:
• Humidifier Model Number • Part Name • Part Number
• Humidifier Manufacturing Date (see label on side near drains)
Figure 11 - Parts Diagram of Models 60-1, F60-1, 60-2 and F60-2
Table 2
