33
Ref. Part
No.
Number Description
BRAKE LINKAGE
1 04019-04 Serr. Fl. HH Nut, 3/8-16
2 04021-05 Hex Locknut, 3/8-16
3 43032 Swivel
4 04062-01 Hairpin Cotter (.094 x 1.62)
5 04001-32 Hex Head Bolt, 3/8-16 x 1-1/4"
6 43212 Sleeve, Hydro Linkage
7 421338 Link, Cam
8 48342 Grip, Parking Brake
9 45504 Handle, Parking Brake
10 04041-07 Flat Washer, 3/8 (.391 x .938 x .105)
11 04021-09 Hex Nut, Elastic Stop 3/8-16
12 04003-11 Carriage Bolt, 3/8-16 x 1-1/4"
13 04001-21 Hex Head Bolt, 3/8-16 x 1-3/4"
14 421339 Lever, Brake
15 04020-12 Hex Jam Nut, 3/8-16
16 43260 Washer, Neutral Lock
17 04017-27 Serr. Fl. HH CPSCR, 3/8-16 x 1"
18 45647 Bracket, Neutral Lock
19 44085 Rod, Neutral Lock
20 48881 Cable Assembly, Parking Brake R.H.
21 48880 Cable Assembly, Parking Brake L.H.
22 48045 Cable Winch
23 04070-03 Eye Bolt, 3/8-16 R.H.
24 04020-04 Hex Nut, 3/8-16
* Common hardware should be purchased locally. All bolts are grade 5 plated; all other fasteners are zinc plated.
