Scag Power Equipment STHM - Manual (Page 25)

23
Ref. Part
No.
Number Description
1 48711 Tank, Hydraulic
2 481164 Cap, Hydraulic Tank
3 48634 Hose, Pump to Oil Cooler
4 48942 Hose, Oil Cooler to Tank
5 48136-04 Clamp, Hose
6 48936-01 Coupling, Flare Swivel
7 48572-05 Tube, Union
8 48645 Oil Cooler Assembly
9 04003-12 Carriage Bolt, 5/16-18 x 3/4"
10 421279 Bracket, Oil Cooler
11 48350-05 Elbow, 90 Degrees
12 48603-02 O-Ring
13 48936-02 Coupling Flare Swivel
14 04019-03 Serr. Fl. Hex Head Nut, 5/16-18
15 421280 Brace, L.H. Cooler Support
16 421281 Brace, R.H. Cooler Support
17 04021-08 Elastic Stop Nut, 1/4-20
18 04017-05 Serr. Fl. Hex Head CPSCR, 1/4-20 x 3/4"
19 421288 Strap, Oil Tank
20 481507 Filler Neck Insert
21 48482 Hose, 1/4" Pushlock, Order by the inch
22 48059-01 Clamp
23 48309 Bushing
24 48939 90 Degree Elbow
UPPER HYDRAULICS
* Common hardware should be purchased locally. All bolts are grade 5 plated; all other fasteners are zinc plated.
