Scag Power Equipment STHM - Manual (Page 33)

31
36 481894 Rim Only
37 48005 Rear Wheel Assy. (includes items 33-36, 37A)
37A 481893 Tire Only
38 43021 Sleeve, Rear Wheel
39 43020-02 Spacer, Rear Wheel
40 48828 Cable, Steering (includes Hardware)
41 45606 Pedal, Foot Safety Switch
42 48114-04 Grease Fitting
43 04021-11 Hex Elastic Stop Nut, 7/16-14
44 04010-17 Screw, Phillips flat hd #10-32 x 3/4"
45 04019-02 Serr. Fl. Hex Nut, 1/4-20
46 481056 Spring, Foot Safety Switch
47 04021-08 Hex Nut, Elastic Stop Lock, 1/4-20
48 481476 Switch, Foot Safety
49 04001-02 Bolt, Hex Hd., 1/4-20 x 1-3/4"
50 45009 Steering Shaft
51 04050-02 Retaining Ring 3/4 Ext. “E”
52 48100-06 Bushing, Oilite - 3/4 ID x 1.0
53 45502 Foot Pedal
54 04010-22 Screw w/washer, 1/4-20 x .75"
55 04041-08 Flat Washer, 3/4 x 1-1/4 x 16 Ga.
56 45506 Foot Pedal Arm
57 04065-01 Pin, Drive Lock 3/16 x 1-1/4"
58 48100-03 Bushing, Oilite - 3/4 x .50 Flanged
59 45488 Sulky Mtg. Brkt. L.H.
60 45256 Sulky Mtg. Brkt. R.H.
61 04001-37 Bolt, Hex Hd., 1/2-13 x 5-1/2"
62 48208 Pulley, Winch Cable
63 48100-04 Bushing, Oillube - 1/2 ID x .56
64 04040-13 Flat Washer, 1/2 (.562 x 1.375 x .109)
65 44028 Retainer, Winch Cable
66 04021-07 Hex Elastic Stop Nut, 1/2-13
67 482109 Arm Rest Bracket, Left Hand
68 482110 Arm Rest Bracket, Right Hand
Ref. Part
No. Number Description
Ref. Part
No.
Number Description
1 46715 Steering Frame (includes Bshgs and Fittings)
2 48100-01 Bronze Bushing, 7/8 ID x 1.0 Flanged
3 04050-03 Retaining Ring, 7/8 external
4 04021-10 Hex Nut, Elastic Stop 5/16-18
5 04040-15 Flat Washer, 5/16 (3/8 x 7/8 x 13 ga.)
6 46029 Steering Handle (includes item 7)
7 48159 Grip
8 04001-12 Bolt, Hex Hd., 5/16-18 x 1-3/4"
9 482119 Seat Assy. (includes items 10 thru 13,54)
10 482111 Cushion Assembly
11 482108 Arm Pad - R.H.
12 482105 Seat Back Cushion
13 482107 Arm Pad - L.H.
14 04019-03 Serr. Fl. HH. Nut, 5/16-18
15 46570 Seat Adjuster Track
16 04003-05 Bolt, RDHD Carr. 3/8-16 x 1-1/2 (52" & 61")
04003-03 Bolt, RDHD Carr. 3/8-16 x 2.0" (72")
17 421342 Seat Plate
18 42482 Ballast, Seat Mount (72" cutter deck only)
19 04019-04 Serr Fl. Hex Nut, 3/8-16
20 42026 Seat Spring
21 04001-83 Bolt, Hex Hd., 7-16-14 x 3-1/2"
22 42366 Reinforcement, Seat Spring
23‘ 04050-05 Retaining Ring, 1-1/8" external
24 48100-02 Bushing, Oilite - 1-1/8 ID x 1.0 Flanged
25 45008 Rear Wheel Pivot
26 04001-32 Bolt, Hex Hd., 3/8-16 x 1-1/4"
27 * Hex Jam Nut, 3/8-24
28 * Lock Washer, 3/8 Internal Tooth
29 45035 Rear Wheel Yoke
30 04021-13 Hex Elastic Stop Nut, 5/8-11
31 04001-40 Bolt, Hex Hd. 5/8-11 x 9"
32 43020-01 Spacer, Rear Wheel, short
33 481897 Seal, Grease
34 481896 Bearing Cone
35 481895 Bearing Cup
* Common hardware should be purchased locally. All bolts are grade 5 plated; all other fasteners are zinc plated.
RIDER FRAME ASSEMBLY
