Scag Power Equipment STHM - Manual (Page 31)

29
INSTRUMENT PANEL AND ELECTRICAL COMPONENTS
Ref. Part
No. Number
Description
1 461360 Instrument Panel (includes Decal)
2 48298 Blade Fuse, 20 amp.
3 482289 Decal, Instrument Panel
4 48023 Hour Meter (includes Bracket and Hardware A, B, C)
A * Hour Meter Bracket
B * Lockwasher, #10 Ext. Tooth
C * Hex Nut, 10-24
5 481755 Ammeter (includes Bracket and Hardware D, E, F)
D * Ammeter Bracket
E * Lockwasher, #10 Int. Tooth
F * Hex Nut, #10-32
6 04010-11 Phillips Rd. Head Screw, #10-32 x 1-1/2"
7 42413 Bracket, Fuse Holder
8 04021-01 Elastic Stop Nut, #10-32
9 04003-12 Carriage Bolt, 5/16-18 x 3/4"
10 04010-01 Phillips Washer Head Screw, #10-32 x .50"
11 48798 Keyswitch
12 * Lockwasher, 5/8 Int. Tooth
13 * Nut, Special 5/8-32
14 48017-02 Ignition Key and Ring Assy.
15 482315 Choke Control (includes hardware)
16 48879 Throttle Control
17 04031-01 Lockwasher, #10 Ext. Tooth
18 04020-01 Hex Nut, #10-32
19 481687 Switch, PTO
20 481275 Wire Harness With Relay
21 04019-03 Serr. Fl. HH Nut, 5/16-18
22 482700 Battery (Not sold through Scag)
23 04001-44 Bolt, Hex head 1/4-20 x 1/2"
24 04020-02 Hex Nut 1/4-20
25 481683 Wire Harness, STHM
26 04031-09 Lockwasher 5/16 Int. Tooth
27 481776 Engine, 23 HP Kohler CV(Spec PS-75523)
28 481474 Switch, Parking Brake
29 481476 Switch, Foot Safety
30 461397 Clutch, Electric
31 04003-12 Carriage Bolt, 5/16-18 x 3/4"
32 48030-09 Wireloom
33 04021-10 Locknut, Elastic Stop 5/16-18
34 48029-15 Battery Cable, 36" Black
35 48029-13 Battery Cable, 25" Red
* Common hardware should be purchased locally. All bolts are grade 5 plated; all other fasteners are zinc plated.
