Scag Power Equipment STHM - Manual (Page 23)

21
Ref. Part
No.
Number Description
1 04003-01 Carriage Bolt, 1/4-20 x 6"
2 423308 Battery Box
3 04029-01 Nut, Wing 1/4-20
4 48015 Battery
5 42392 Battery Cover
6 48099 Insulation, Battery Cover
7 48292 Pad, Fuel Tank Strap
8 481556 Cap, Fuel Tank
9 46846 Fuel Tank Assy. (Includes items 10 - 11)
10 48309 Bushing, Fuel Tank Valve
11 48308 Fuel Shut Off Valve
12 421239 Strap, Fuel Tank
13 04010-10 Phil RDHD Machine Screw 1/4-20 x 2"
14 04020-02 Hex Nut, 1/4-20
15 48205 Pad, Fuel Tank Support
16 04003-12 Carriage Bolt, 5/16-18 x 3/4"
17 42377 Support, Fuel Tank
18 421522 Bracket, Fuel Tank Support
19 04019-03 Serr. Fl. Hex Nut 5/16-18
20 04031-09 Lockwasher, 5/16 Int. Tooth
21 481776 Engine, 23 HP Kohler CV, (Spec PS-75523)
22 04001-12 Hex Head CPSCR, 5/16-18 x 1-3/4"
23 482352 Oil Drain Extension
24 422534 Plate, Backing
25 45586 Engine Deck
26 48030-09 Wire Loom, .50 I.D.
27 04040-14 Washer, 1/4 (.312 x .750 x .065)
28 04001-72 Bolt, Hex Head 1/2-13 x 2"
29 43041 Sleeve, Shock Absorber Mount
30 48516 Shock Absorber
31 04021-07 Hex Locknut, Elastic Stop 1/2-13
32 04017-42 Serr. Fl. Hex Head CPSCR, 7/16-14 x 1"
33 04019-05 Serr. Fl. Hex Nut, 7/16-14
34 48769 Motor - White (Includes item 52)
35 04030-06 Lockwasher, 1/2"
35A 04020-07 Nut, 1/2-13
36 421289 Anchor, Brake
37 04001-59 Bolt, Hex Head 1/4-20 x 1-1/4"
38 04019-02 Serr. Fl. Hex Nut, 1/4-20
39 04017-16 Serr. Fl. Hex Head CPSCR, 5/16-18 x .75"
40 48461 Parking Brake Assembly (Incl. 41-44)
41 48461-02 Brake Pads- Pair
42 48461-03 Springs - Pair
43 48461-04 Actuating Arm, Incl. Pin & Clip)
44 48461-05 Clip
45 46929 Hub Assembly (Includes item 50)
46 48513 Brake Drum
47 48933 Rim and Tire Assembly (Includes items 48, 49)
48 48933-02 Tire 20 x 10 x 10, 4 Ply
49 48416-04 Rim Only
50 04008-03 Bolt, Hub
51 04028-01 Wheel Nut
52 48680 Castle Nut, 1.0-20 UNEF
53 43261 Spacer, Clutch
Ref. Part
No.
Number Description
54 04063-06 Key, 1/4 x 1/4 x 1-1/2"
55 04012-04 Hex Socket Set Screw, 5/16-18 x 3/8"
56 48792 Pulley, Engine Pump Drive (Incl. 55)
57 461397 Clutch, Electric (Ogura)
58 04041-28 Flatwasher, 7/16 (.469 x 1.75 x .25)
59 04030-05 Lockwasher, 7/16"
60 04102-05 Bolt, Hex Head 7/16-20 x 2.75"
61 04021-10 Hex Locknut, Elastic Stop 5/16-18
62 422533 Backing Plate, Clutch Stop
63 481716 Rubber Pad, Clutch Stop
64 481641 Heatshield, Muffler
65 04001-12 Bolt, Hex Head 5/16-18 x 1-3/4"
66 04063-12 Key, Woodruff 3/16 x 5/8"
67 48581 Pulley, Pump Input
68 43117 Sleeve, Idler
69 04050-06 Ring, Retaining, 1-9/16 Internal
70 48854 Belt, Pump Drive
71 46370 Pulley, Idler-Traction Drive (Incl. 68,69,72)
72 48102 Bearing, Idler Pulley
73 43063 Spacer, Idler
74 46327 Pump Idler Arm (includes items 76, 79)
75 45037 Idler Pivot Base
76 48100-05 Bushing, Oillube
77 04041-08S Flatwasher, 3/4"
78 04050-02 Ring, Retaining, 3/4" Ext. "E"
79 48114-04 Grease Fitting
80 04020-12 Hex Nut, Jam 3/8-16
81 04001-62 Bolt, Hex Head 3/8-16 x 3-1/4"
82 48929 Spring, Pump Drive Idler
83 04019-04 Serr. Fl. Hex Nut, 3/8-16
84 04061-04 Cotter Pin, 5/32 x 1.50"
85 04001-47 Bolt, Hex Head 3/8-16 x 5"
86 04015-03 Socket Head CPSCR, 1/2-13 x 1-1/4"
87 04030-06 Lockwasher, 1/2"
88 04041-04 Flatwasher, 1/2 (.516 x .938 x .105)
89 481100 Pump, Sundstrand
90 421520 Bracket, Oil Tank Support
91 04001-21 Bolt, Hex Head 3/8-16 x 1-3/4"
92 04041-10 Washer 2" OD, 3/8 ID, 16 Ga.
93 04003-02 Carriage Bolt, 1/4-20 x 3/4"
94 421523 Guard, Pulley
95 421521 Gusset, Battery Box
96 421705 Support, Battery Box
97 04003-04 Carrage Bolt, 5/16-18 x 1"
98 48030-10 Wire Loom, .75" I.D.
99 48661 Rubber Pad
100 48058 Fuel Hose, Order by the inch
101 48059-01 Clamp, Fuel Hose
102 04001-52 Bolt, 1/2-13 x 2.50"
103 04021-08 Nut, 1/4-20 Elastic Stop
ENGINE DECK
* Common hardware should be purchased locally. All bolts are grade 5 plated; all other fasteners are zinc plated.
