Control linkage – Scag Power Equipment STHM User Manual
Page 29
27
Ref. Part
No.
Number
Description
1
46328
Control Linkage, Bellcrank (Includes 30, 31)
2
04040-15
Flatwasher, 5/16 (.375 x .875 x .083)
3
04001-13
Bolt, Hex Head 5/16-18 x 2-3/4"
4
04001-19
Bolt, Hex Head 3/8-16 x 1"
5
04040-05
Flatwasher, 3/8 (.406 x .812 x .065)
6
43212
Sleeve, Pump Control Link
7
42658
Link, Speed Control
8
04021-05
Hex Locknut, 3/8-16
9
45485
Control Arm, Pump
10
04003-05
Carrage Bolt,RH SH SQNK 3/8-16 x 1-1/2"
11
04041-07
Flatwasher, 3/8 (.391 x .938 x .105)
12
48464
Rod End, RH Female THD 3/8-24
13
04021-09
Hex Locknut, Elastic Stop 3/8-16
14
04020-14
Hex Nut, 3/8-24
15
44044
Control Rod
16
48512
Bolt Hex Head, 3/8-24 x 6-3/4"
17
43257
Bushing, Spring Keeper
18
48463
Spring, Neutral Return
19
421148
Retainer, Neutral Spring
20
04003-04
Carrage Bolt, 5/16-18 x 1"
21
04019-03
Serr. Fl. Hex Nut 5/16-18
22
**
Number Not Used
23
04001-59
Bolt, Hex Head 1/4-20 x 1-1/4"
24
04021-08
Hex Locknut, Elastic Stop 1/4-20
25
04021-10
Hex Locknut, Elastic Stop 5/16-18
26
43110
Sleeve, Control Arm
27
04061-02
Cotter Pin, 3/32 x .75"
28
48343-04
Clevis, Pump Control
29
04064-02
Pin, Clevis 3/8"
30
48114-05
Greese Fitting, 1/4-28 Self Tap
31
48100-04
Bushing, Bronze
* Common hardware should be purchased locally. All bolts are grade 5 plated; all other fasteners are zinc plated.
CONTROL LINKAGE
