-18-

Model W1815 (Mfg. Since 10/10)

O

PE

R

ATIO

NS

The Model W1815 sander accepts 15" diameter adhesive-

backed sanding discs. These are available in a variety of

grits.

The sanding disc sticks to the surface of the cast iron

disc platen, using the pressure-sensitive adhesive backing

(PSA). The sandpaper can be replaced without removing

either the table or the dust port.

To attach sandpaper, do these steps:

1. DISCONNECT MACHINE FROM POWER!

2. Remove the safety guard, peel off the old sandpaper,

clean the disc surface with mineral spirits, and wipe

it dry.

3. Peel back the protective layer on one-half of the

sandpaper disc and fold it against the remaining

half.

4. Slip the half with the protective layer between the

disc and the table edge (see

Figure 12).

5. Position the exposed adhesive on the upper half of

the disc that extends above the table. Once it is

positioned evenly across the disc, press the adhesive

onto the surface.

6. Rotate the disc so the lower half is above the table.

Peel off the other half of the protective paper, and

press the remaining sandpaper against the disc so

adhesion is complete.

7. Re-install the safety guard.

Attaching Sandpaper

Figure 12. Sandpaper being slipped

between the disc and table.
