Appendix B
Slot Combinations
This appendix lists the IOA slot combinations and contains the following sections:
■
IOA Slot Combinations
Depending on the software release and IOA type, you must install IOAs in certain
slots and bays combined with other IOAs in the same slot:
■
You must insert some IOAs only in the upper bay (Adapter 0) of each IOA module
slot. If you insert one of these IOAs into a lower bay slot, the line module
diagnostics fail, an error message states that the bottom slot is not supported
for the currently installed software release, and the slot is disabled.
■
If you insert an unrecognized IOA, such as an IOA that is not supported by a
particular software release, the line module diagnostics fail, an error is generated,
and the slot is disabled.
■
If you remove an IOA and replace it with a different IOA in the same slot, an
error message states the mismatch and the slot is disabled.
■
Full-height IOAs take up the entire slot (both Adapter 0 and Adapter 1).
For information about working with modules and IOAs, see JUNOSe System Basics
Configuration Guide, Chapter 6, Managing Modules. See
currently available IOAs and the bays in which you may insert them.
Table 22: E320 IOA Locations and Combinations
Combined with Other
IOAs in Same Slot
Both Bays
Concurrently
Lower Bay (Adapter
1)
Upper Bay (Adapter
0)
IOA
No
No
Yes
Yes
ES2-S1 GE-4
Yes (GE-8 when
paired with ES2 4G
LM or ES2 10G LM;
GE-8, OC3/STM1, and
OC12/STM4 IOAs
when paired with ES2
4G LM)
Yes
Yes
Yes
ES2-S1 GE-8
