Up to four LC-style fiber-optic connectors
■
Transmit power:
■
min: –2 dBm
■
max: 3 dBm
■
Receive input power:
■
min: –22 dBm
■
max: –3 dBm
■
See the following corresponding table (ZX Fiber Optic Cabling) for cabling
requirements.
■
See E320 Hardware Guide, Chapter 5, Cabling the Router for more information.
Cables and connectors
(single-mode [ZX] )
When lit, LED indicates:
■
OK (green)—Physical link is connected properly and is functioning properly
■
FAIL (red)—Failure detected
■
Port LEDs:
■
LK (green)—Ethernet link is up
■
ACT (green)—Blinks when there is Ethernet traffic being received
LEDs
■
See Monitoring Ethernet Interfaces in JUNOSe Physical Layer Configuration Guide,
Chapter 5, Configuring Ethernet Interfaces.
Alarms, errors, and events
Table 2: SX Fiber Optic Cabling
Maximum Operating Range (meters)
Minimal Modal Bandwidth at
850 nm (MHz*km)
Fiber Type
220 (656.17 ft)
160
62.5 microns
275 (902.23 ft)
200
500 (1640.42 ft)
400
50 microns
550 (1804.46 ft)
500
Table 3: LX Fiber Optic Cabling
Maximum Operating Range
(kilometers)
Nominal Wavelength (nm)
Fiber Type
10 (6.2 miles)
1310
9 microns
Table 4: LX40 Fiber Optic Cabling
Maximum Operating Range
(kilometers)
Nominal Wavelength (nm)
Fiber Type
40 (24.85 miles)
1310
9 microns
20
■
GE-4 IOA
