Table 10: SR Fiber Optic Cabling
Maximum Operating Range (meters)
Minimal Modal Bandwidth at
850 nm (MHz*km)
Fiber Type
26 (85.3 ft)
160
62.5 microns
33 (108.27 ft)
200
66 (216.54 ft)
400
50 microns
82 (269.03 ft)
500
300 (984.25 ft)
2000
Table 11: LR Fiber Optic Cabling
Maximum Operating Range
(kilometers)
Nominal Wavelength (nm)
Fiber Type
10 (6.2 miles)
1310
9 microns
Table 12: ER Fiber Optic Cabling
Maximum Operating Range (kilometers)
Nominal Wavelength (nm)
Fiber Type
40 (24.85 miles)
1550
9 microns
28
■
10GE IOA
E320 8.1.x Module Guide
