15

ENGLISH

1 Starting the communication: connection command

(!00BCN1Cr)

3 Selecting “SDI 1” input (!00BINACr)

5 Terminating the communication: termination command

(!00BCN0Cr)

6 Monitor’s status (@00BOKCr)

4 Monitor’s status (@00BOKCr)

2 Monitor’s status (@00BOKCr)

PC, etc.

Monitor

This is a female
terminal.

Pin No.

IN terminal

signal

OUT

terminal

signal

1

TXD +

TXD +

2

TXD –

TXD –

3

RXD +

RXD +

4

NC

NC

5

NC

NC

6

RXD –

RXD –

7

NC

NC

8

GND

GND

This is a female
terminal.

Pin No.

Signal

1

NC

2

RXD

3

TXD

4

NC

5

GND

6

NC

7

RTS

8

CTS

9

NC

• The 7th terminal and the 8th terminal

are connected.

Operation

1

Set “PARALLEL TYPE” of “REMOTE SETTING” to “MAKE” or “TRIGGER” in the SET-UP MENU.

2

Short-circuit the 7th pin terminal (ENABLE) to the 8th pin terminal (GND) so that the monitor can be controlled

by the external control.

3

When selecting “MAKE” system: Operate each function by short-circuiting the corresponding pin terminal to

the 8th pin terminal (GND) or opening it.
When selecting “TRIGGER” system: Operate each function by pulse control, that is short-circuiting the
corresponding pin terminal to the 8th pin terminal (GND) for about 1 second and opening it.

• When changing the input with MAKE system, only one pin terminal must be short-circuited. (Other pin terminals

must be opened.)

• When selecting the “TRIGGER” system, you can operate only one function at a time. Operate the functions one

by one.

7 Using the serial communication

You can control the monitor from a personal computer etc. via the RS-485 or RS-232C terminal.
• Consult your dealer for the details of the external control specification.

Input terminal

Cable

Terminal

specification

Communication specifications

RS-485

A straight LAN cable

☞ See the right

Baud Rate: 4800 bps
Data Bits: 8 bits
Parity: No parity
Stop Bits: 1 bit
Flow Control: No control
Communication Code: ASCII Code

RS-232C

A straight cable with a D-sub 9-pin
connector (male for the monitor,
female for the personal computer
etc.)


All commands consist of the following segments.

Header

Monitor ID

Command ID

Function

Data

Cr (0DH)

Header

“!”: Operation commands from the personal computer, etc. For details, see on the right.
“?”: Reference commands from the personal computer, etc.
“@”: Status returns from the monitor

• To start communication, send the connection command from the personal computer etc.
• To terminate the communication, send the termination command from the personal computer etc.

Example of communication procedures

No.

Commands

Functions

Data

1

!

* **

1

B C N 1

Cr

Starts communication (connection)

No data

2

!

* **

1

B C N 0

Cr

Terminates communication (termination)

No data

3

!

* **

1

B I

D S E T

x

x*

2

Cr

Assigns the control ID

01 – 99

4

!

* **

1

B I

D R E T

Cr

Initializes the control ID

No data

5

!

* **

1

B I

D D S P

x

x*

2

Cr

Displays/hides the ID

00: Hide
01: Display

6

!

* **

1

B I

D C H K

x

x*

2

Cr

Flashes/hides the selected ID No. of the monitor

00: Hide
01: Display

7

!

* **

1

B M E N U Cr

Displays the MAIN MENU/Quits the menu
operation

No data

8

!

* **

1

B U P Cr

Moves the cursor upward ( )

No data

9

!

* **

1

B D O W N Cr

Moves the cursor downward ( )

No data

10

!

* **

1

B A D J

R Cr

Makes setting/adjustment ( )

No data

11

!

* **

1

B A D J

L

Cr

Makes setting/adjustment ( )

No data

12

!

* **

1

B S E T U P

Cr

Displays the SET-UP MENU

No data

13

!

* **

1

B P W 1

Cr

Turns on the monitor

No data

14

!

* **

1

B P W 0

Cr

Turns off the monitor (on standby)

No data

15

!

* **

1

B I

N A Cr

Selects “SDI 1” input

No data

16

!

* **

1

B I

N B Cr

Selects “SDI 2” input

No data

17

!

* **

1

B I

N C Cr

Selects “DVI” input

No data

18

!

* **

1

B I

N D Cr

Selects “COMPO.” input

No data

19

!

* **

1

B I

N E Cr

Selects “VIDEO” input

No data

20

!

* **

1

B D I

S P Cr

Displays the status*

3

No data

21

!

* **

1

B A M U T E

x

x*

2

Cr

Turns muting on/off

00: Off, 01: On

22

!

* **

1

B A S P x

x*

2

Cr

Changes the aspect ratio

00: 4:3, 01: 16:9

• “Cr” is 0Dh.
• The commands for starting communication (connection) (No. 1), terminating communication (termination)

(No. 2), and turning on the monitor (No. 13) can be used while the monitor is off (on standby).

*

1

Enter the monitor’s ID for “ **.” The initial setting of the monitor’s ID is “00.” When connecting several monitors, “00” is a

command for controlling all monitors at once.

*

2

Enter the appropriate data to “xx”.

*

3

Displays the information shown when INPUT SELECT button of the current input is pressed (

“About the Status

Display” on page 7).
