9
Basic Menu Operations
7About the Menu Screens
This monitor features MAIN MENU which contains the functions normally used and SET-UP MENU which contains
the initial settings of the monitor.
MAIN MENU
Items Functions
APERTURE CONTROL Compensates the frequency characteristics of the luminance signal of a video signal.
sub menu SELECT Selects the positions and the contents of the sub-menu display.
MARKER Controls ON/OFF and other settings of the MARKER SELECT, ASPECT SELECT, and SAFETY
MARKER functions included in the MARKER function.
ASPECT Selects the aspect ratio.
DEGAUSS on Degausses the screen.
SET-UP MENU
Items Functions
FUNCTION SETTING Sets the control systems for the COLOR SYSTEM, synchronized signal, RUSH DELAY TIME, colors
of the tally lamp, groups of the audio output modes, and MAKE/TRIGGER terminal.
• Can be also used to check the amount of time that the monitor has been used.
PICTURE SUB ADJ. The standard value (“00”) of the picture adjustment is initially set at the factory. You can adjust the
standard value as you want.
COLOR TEMP./BAL. Sets or adjusts the color temperature and white balance.
SIZE/POSI. ADJ. Adjusts the size and position of the picture.
DISTORTION ADJ. Compensates the picture distortion, tilt, and the color heterogeneity caused by geomagnetic
influence.
STATUS DISPLAY Sets the items related to the display screens, such as the status display or the AUDIO LEVEL
METER display.
CONTROL LOCK Prohibits altering the monitor operations except turning the monitor on/off and deactivating this
function.
• Operating the monitor by the external control is available if this function is activated.
all reset Resets all the settings you have made to factory-preset values.
• Adjustments made by using the front panel buttons will also be reset.
NOTE:
• Some items may not appear on the menu depending on the input or the input signal. Those items are not available to use.
7Buttons for Menu Operations
CHROMA/PHASE button
To display SET-UP MENU, press
the CHROMA/PHASE button
while moving the MENU control
to .
MENU control
Displays or closes a menu
screen.
While a menu screen is
displayed, selects or adjusts the
menu items by moving the
control to / / / .
