AJ-64 Conveyor Series Technical Manual 7610-003-30-93
Issued: 05-02-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
OPERATING CHARACTERISTICS
2
RACKS PER HOUR:
AJ-64-86-100CE/CS/CGP 287
DISHES OR GLASSES PER HOUR:
AJ-64-86-100CE/CS/CGP 7200
PREWASH TANK CAPACITY (GALLONS):
AJ-86CE/CS/CGP 16
AJ-100CE/CS/CGP 16
WASH TANK CAPACITY (GALLONS):
AJ-64-86-100CE/CS/CGP 15.4
POWER RINSE TANK CAPACITY (GALLONS):
AJ-86CE/CS/CGP 15.4
AJ-100CE/CS/CGP 15.4
PREWASH PUMP CAPACITY (GPM):
AJ-86CE/CS/CGP 120
AJ-100CE/CS/CGP 270
WASH PUMP CAPACITY
GALLONS PER MINUTE (ALL MODELS): 270
POWER RINSE PUMP CAPACITY
GALLONS PER MINUTE (ALL MODELS): 270
VENTING REQUIREMENTS (CFM)(100% CAP.):
INPUT END 200
OUTPUT END 400
TOTAL 600
CONVEYOR SPEED (FPM):
AJ-64-86-100CE/CS/CGP MACHINES 8.0
GALLONS PER RACK:
AJ-64-86-100CE/CS/CGP MACHINES .77
WATER TEMPERATURES:
AJ-64-86-100CE/CS/CGP MODELS:
WASH (MINIMUM) 150 °F
POWER RINSE (MINIMUM) 160 °F
FINAL RINSE (MINIMUM) 180 °F
FLOW PRESSURE (PSI) 20 ±5
FLOWRATE (GPM):
AJ-64-86-100CE/CS/CGP 3.7
STEAM COIL TANK HEAT (CS MODELS ONLY):
STEAM INLET PRESSURE (PSIG) 10-20
STEAM CONNECTION NPT 3/4”
CONSUMPTION @ 15 PSIG (lbs/hr):
AJ-64-86-100CS/CSL
100
MOTOR ELECTRICAL CHARACTERISTICS:
DRIVE MOTOR HP 1/4
WASH MOTOR HP 2
POWER RINSE MOTOR HP 2
PREWASH MOTOR HP:
AJ-86 MODELS
1
AJ-100 MODELS 2
NOTE: Typical Electrical Circuit is based upon (1) 125% of
the full amperage load of the machine and (2) typical
fixed-trip circuit breaker sizes as listed in the NEC 2002
Edition. Local codes may require more stringent protec-
tion than what is displayed here. Always verify with your
electrical service contractor that your circuit protection is
adequate and meets all applicable national and local
codes. These numbers are provided in this manual sim-
ply for reference and may change without notice at any
given time.
