12
VCR
OUT(REC) IN(PLAY)
AUDIO
OUT(REC) IN(PLAY)
VCR
Å
ı О ‰ П М З
Y
P B
P R
COMPONENT VIDEO
MONITOR
OUT
DVR/DVD
IN
VCR(DBS)
IN
Å
7 Connecting a VCR
Turn off all components before making connections.
• When you connect other components, refer also to their manuals.
Å To component video output
• Connect Y, P B , and P R correctly.
ı To left/right audio channel output
Ç To left/right audio channel input
Î To composite video output
‰ To S-video output
Ï To S-video input
Ì To composite video input
Stereo audio cable
(not supplied)
White
Red
White
Component video cable (not supplied)
Composite video
cable (not supplied)
S-video cable (not supplied)
Red
Green
Blue
Red
VCR
NOTES
• Select the audio and video input setting according to the
connection method. See pages 16 and 17 for details.
• When connecting a VCR to the component video input jacks,
select “CMPNT SELECT” (see page 26) to “VCR.” If you do not,
you cannot view the playback picture on the TV or the AV
COMPU LINK remote control system (see page 38) cannot
operate properly.
• You can enjoy digital sound if using a digital coaxial or optical
cable. When shipped from the factory, the digital optical terminal
(DIGITAL IN 3 (VCR)) on the rear of the receiver is set for a
VCR. For details of digital audio connection, see page 14.
Composite video cable (not supplied)
Do not connect the AC power plug to the wall outlet until all connections are completed.
: signal current
