1
UV10
PREPARATION
Congratulations on your purchase of the Jensen Phase
Linear UV10 Mobile Multimedia Receiver.
It’s a good idea to read all of the instructions before beginning
the installation. We recommend having your Jensen Phase
Linear UV10 installed by a reputable installation shop.
Features
DVD
•
Aspect Ratio - Full and Normal
• Fast Forward - 2X, 4X, 8X and 32X
• Slow Motion - 1/2, 1/4, 1/6 and 1/7
• Play, Pause, Stop, Next Chapter and Previous Chapter
CD / MP3 / WMA
•
CD-Text Compatible
• ID3 Tag Compatible
• Directory Search (MP3 / WMA Only)
• Direct Track Access via Remote Control
• Burn up to 1500 MP3 and WMA Files onto a DVD+R /
RW
• Audible Forward / Reverse Track Search (CD-DA Only)
• Random, Repeat and Intro
• Play, Pause, Stop, Next Track and Previous Track
AM-FM
•
USA / Europe / Latin America / Asia Frequency Spacing
• 30 Station Presets (18 FM / 12 AM)
• Auto Stereo / Mono
• Local / Distance
• Auto Store / Preview Scan
iPod
•
iPod via USB
• High Speed Direct Connect Interface to Access iPod
Playlists, Artists, Albums and Songs. Play music and
view video/photo* files from your iPod. *Video/photo
playback requires jLink-USB iPod interface cable (sold
separately).
• Power Management Charges iPod while Connected
Chassis
•
1.0 DIN (Import / ISO-DIN Mountable)
• Motorized Flip-Out / Flip-Up LCD Screen
• 8 Character / Segment Type Secondary LCD Display
• 7" TFT Active Matrix LCD
• 336, 960 Sub Pixels (1440W X 234H)
• Screen Tilt / Angle Adjustment
• Beep Tone Confirmation (On-OFF Option)
• Heat Management System - Forced Air-Cooling To
Keep The Chip-Sets Operating at Nominal
Temperatures
General
•
Navigation Ready (NAV102)
• Bluetooth Ready (with purchase of BTM10) providing
hands-free profile for safety / convenience and A2DP
profile for streaming music from a PDA / PMP
• 44-Key Infrared Remote Control
• One Composite Video Output for Additional Screens
• Front Panel Audio/Video Input
• Three-Band Tone control (Bass, Mid and Treble) w/
Eight Preset EQ Curves
• Front Panel A/V Aux Input for Portable Media Devices
• Front, Rear and Subwoofer Line Output
• Programmable Volume Control
• Rear Camera Input (Normal and Mirror Image View)
• Touch Screen Calibration Mode
• 2VRMS Line Output - All Channels
• Rotary Encoder Audio Control
• SWC Interface – Compatible with PAC adapter SWI-PS
Steering Wheel Control Interface, sold separately
Optional Equipment
• NAV102
The UV10 is "navigation ready." Before accessing any
navigation features, you must purchase and install the
navigation module (NAV102). All installation and
operating instructions will be included with the
navigation module.
Once the navigation module is connected and operating
properly, the NAV source mode will become active.
While the navigation module is not installed, the NAV
option appears gray, indicating the function is not
available.
• BTM10
Before you can connect to a Bluetooth enabled device,
you must purchase and install the Jensen BTM10.
• Bluetooth Phone
See “Bluetooth Operation” on page 21.
• Rear Camera
The UV10 is "camera ready." Before accessing any
camera features, you must purchase and install a rear
video camera. Once the rear camera is connected and
operating properly, the CAMERA source mode will
become active. While the camera is not installed, the
CAMERA option appears gray, indicating the function is
not available.
WARNING! Never install this unit where operation and
viewing could interfere with safe driving conditions.
WARNING! To reduce the risk of a traffic accident (except
when using for rear view video camera) never use the
video display function while driving the vehicle. This is a
violation of federal law.
WARNING! Never disassemble or adjust the unit.
WARNING! To prevent injury from shock or fire, never
expose this unit to moisture or water.
WARNING! Never use irregular discs.
WARNING! To prevent damage to the mechanism inside
this unit, avoid impact to the TFT monitor.
WARNING! The monitor employs an automatic motorized
mechanism. To prevent damage to the core mechanism,
please do not push, pull or swivel the monitor manually.
