Controls and features, 7 rear panel, Cont.) – JVC TM-1011G User Manual
Page 6

6
7 Rear Panel
w Power input connectors
You can use either AC or DC power supply to
operate the monitor.
AC IN:
Connect to an AC outlet with the
provided AC power cord. (AC 120 V/
220-240 V, 50 Hz/60Hz).
DC IN 12 V: Connect the power cord from the DC
power supply (12 V).
NOTES:
• Regarding the DC power supply, consult with your
dealer.
• While connecting both the AC and DC power supply...
– AC power supply is preferentially used.
– If the AC power supply is cut off (for example, when
unplugging the AC power cord), the power supply
automatically switches to the DC power supply.
Controls and Features
(cont.)
w
e
u
r
t
y
1
2
4
3
Pin terminals of the DC IN 12 V connector:
Signal
GND
—
—
DC 12V
Pin No.
1
2
3
4
