5

5 UNDER SCAN button

Reduces the screen size so that the whole screen is
displayed.

6 BLUE CHECK button

Displays the blue video signal only.

7 COLOR OFF button

Displays the luminance signal only.

8 INPUT SELECT buttons/lamps

Select an input to display.
A: Select the video and audio signals input to the

VIDEO A and AUDIO A terminals.

B: Select the video and audio signals input to the

VIDEO B and AUDIO B terminals.

• The corresponding lamp of the input currently

selected lights up.

9 DC INDICATOR lamp

Turns to orange from green when the DC power
voltage lowers. When the voltage becomes lower
than the certain level, the monitor automatically
turns off and the lamp turns to red.
• Make sure to turn off the DC switch on the rear

panel before replacing the battery.

• The length of time the lamp lights in orange differs

depending on the type of the battery or the battery
condition.
It is recommended to replace the battery when the
lamp turns to orange.

p Power lamp

Unlit:

The AC or DC switch on the rear panel is
off.

Orange: The AC or DC switch on the rear panel is

on and the monitor is in stand-by mode.

Green:

The monitor is on.

q Stand-by button

Turns on and off the monitor when the AC or DC
switch on the rear panel is on.

NOTE:
• When using the DC power supply, turning on the DC switch

on the rear panel puts the monitor in stand-by mode. To
turn on the monitor, press the stand-by button.

7 About the status display
Displays information of the current input selection
and the monitor settings for about 3 seconds.
To show the status display, set “STATUS DISPLAY”
to “AUTO” or “MANUAL” beforehand.

☞ “STATUS DISPLAY” on page 13

Pressing the INPUT SELECT button currently
selected shows the status display.

NOTE:
• When “STATUS DISPLAY” is set to “AUTO,” the status

display also appears on the screen if you change the
inputs or the signal condition changes.

1 Signal format

• “NO SYNC” is displayed when no video signal

is input.

• “Out of range” is displayed when a

noncompliant signal is input.

2 Setting of “COLOR TEMP.”

☞ “COLOR TEMP./BAL.” on page 12

“ * ” is displayed if white balance is adjusted in the
“COLOR TEMP./BAL.” menu.

3 Setting of UNDER SCAN

☞ “5 UNDER SCAN button” on the left column

OVER:

Over-scan

UNDER: Under-scan

4 Setting of BLUE CHECK

☞ “6 BLUE CHECK button” on the left column

NORMAL: Normal screen
B ONLY:

Blue screen

5 Setting of COLOR OFF

☞ “7 COLOR OFF button” on the left column

COLOR: Normal screen
MONO:

Monochrome screen
