TM-1011G
Color Video Monitor
10" measured diagonally
Width: 176.9 mm (6 15/16")
Height: 137.6 mm (5 3/8")
Diagonal: 224.5 mm (8 13/16")
H: 15 kHz
V: 50 Hz/60 Hz
6 MHz (–3 dB)
280 TV lines
Composite signal input/output terminals
VIDEO A/VIDEO B: 2 lines, BNC connector x 4 (1 Vp-p, 75 Ω)
* The input (IN) and output (OUT) terminals are bridge-connected. (Auto termination)
Analogue audio input/output terminals
AUDIO A/AUDIO B: 2 lines, RCA connector x 4 (0.5 V (rms), high impedance)
* The input (IN) and output (OUT) terminals are bridge-connected.
Remote input terminal
MAKE/TRIGGER: Point-of-contact connection, 1 line, RJ-45 connector (8-pin) x 1
1 W
8 cm (3 1 / 8 ") round x 1, 8 Ω
INPUT A/B: NTSC (3.58 MHz), PAL (4.43 MHz), B/W (50 Hz/60 Hz)
Operating temperature: 0°C – 40°C (32°F – 104°F)
Operating humidity: 20% – 80% (non-condensing)
AC power: 120 V/220-240 V, 50 Hz/60 Hz
DC power: 12 V
0.9 A (AC 120 V)/0.6 A (AC 220-240 V)
4.3 A (DC 12 V)
Width: 222 mm (8 3 / 4 ")
Height: 229 mm (9 1 / 8 ")
Depth: 338.3 mm (13 3 / 8 ")
7.8 kg (17.2 lbs)
AC power cord
Specifications
Model
Type
Picture Tube
Effective Screen Size
Scanning Frequency
Video Band
Horizontal Resolution
Input/Output Terminals
Audio output
Speaker
Compliant Video Signal
Environmental
Conditions
Power Requirements
Power Consumption
Dimensions
Weight
Accessory
* Illustrations and pictures used in this manual have been exaggerated, abbreviated or compounded for explanatory purposes only.
The appearance of the actual product may differ slightly.
* Dimensions and weight are approximate.
* E. & O.E. Design and specifications subject to change without notice.
