ENGLISH
SPECIFICATIONS
(Rectangular)
FOR ALL UNITS: Electrical Service Requirements: All require a dedicated GFCI protected separate circuit.
SINGLE MOTOR units:
RapidHeat
TM
: 120 VAC, 15 AMP, 60 Hz. dedicated GFCI protected separate circuit.
Motor/Pump: 120 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit.
*
DUAL MOTOR units: (2) Two 230 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuits required.
One (1) Heater and (1) Motor/Pump on each 230 VAC, 20 AMP, 60 Hz. dedicated GFCI protected separate circuit.
NOTE: The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
MODEL
PRODUCT
WEIGHT
OPERATING
GALLONAGE
TOTAL WEIGHT/
FLOOR LOADING
DIMENSIONS
DRAIN/OVERFLOW
CUTOUT
HEATER
FUZION 7260
*
WITH WENGE
DUAL MOTOR
72"
(1829 mm) L
60"
(1524 mm) W
22-3/4" ( 578 mm) H
1849 lb
(840.5 kg)/
61.6 lb/ft
2
(300 kg/m
2
)
319 lb
(145 kg)
FUZION 7260
WITH WENGE
SINGLE MOTOR
LH RH
72"
(1829 mm) L
60"
(1524 mm) W
22-3/4" ( 578 mm) H
1805 lb
(820.5 kg)/
60 lb/ft
2
(293 kg/m
2
)
274 lb
(125 kg)
16-3/4" (425 mm) A
12-1/16" (306 mm) B
71" x 59"
(1803 mm x
1499 mm)
FUZION 7260
UNDERMOUNT
SINGLE MOTOR
LH RH
72"
(1829 mm) L
60"
(1524 mm) W
21-1/2" ( 546 mm) H
16-3/4" (425 mm) A
12-1/16" (306 mm) B
1730 lb
(786 kg)/
57.6 lb/ft
2
(281 kg/m
2
)
199 lb
(90.5 kg)
Template
Provided
P/N
DD44000
FUZION 7260
*
WITH TEAK
DUAL MOTOR
72"
(1829 mm) L
60"
(1524 mm) W
22-3/4" ( 578 mm) H
16-3/4" (425 mm) A
12-1/16" (306 mm) B
1849 lb
(840.5 kg)/
61.6 lb/ft
2
(300 kg/m
2
)
319 lb
(145 kg)
16-3/4" (425 mm) A
12-1/16" (306 mm) B
1805 lb
(820.5 kg)/
60 lb/ft
2
(293 kg/m
2
)
Factory Installed
(S749000 Heater)
Factory Installed
(S749000 Heater)
Factory Installed
(BN60000 Heater)
Factory Installed
(BN60000 Heater)
FUZION 7260
WITH TEAK
SINGLE MOTOR
LH RH
72"
(1829 mm) L
60"
(1524 mm) W
22-3/4" ( 578 mm) H
16-3/4" (425 mm) A
12-1/16" (306 mm) B
274 lb
(125 kg)
Factory Installed
(S749000 Heater)
FUZION 7236
UNDERMOUNT
LH RH
FUZION 7236
WITH TEAK
LH RH
FUZION 7236
WITH WENGE
LH RH
70-11/16" (1795 mm) L
35-3/8" ( 899 mm) W
21-1/2" ( 546 mm) H
70-11/16" (1795 mm) L
35-3/8" ( 899 mm) W
22-3/4" ( 578 mm) H
70-11/16" (1795 mm) L
35-3/8" ( 899 mm) W
22-3/4" ( 578 mm) H
154 lb
(70 kg)
195 lb
(88.6 kg)
195 lb
(88.6 kg)
1238.8 lb
(563 kg)/
68.8 lb/ft
2
(335 kg/m
2
)
1238.8 lb
(563 kg)/
68.8 lb/ft
2
(335 kg/m
2
)
1188.8 lb
(540.4 kg)/
66 lb/ft
2
(321.4 kg/m
2
)
16-3/4" (425 mm) A
12"
(305 mm) B
16-3/4" (425 mm) A
12"
(305 mm) B
16-3/4" (425 mm) A
12"
(305 mm) B
Factory Installed
(S749000 Heater)
Factory Installed
(S749000 Heater)
Factory Installed
(S749000 Heater)
6
Jacuzzi Whirlpool Bath DE99000A 3/06
71" x 35"
(1803 mm x 889 mm)
Template
Provided
P/N
DD42000
SPECIFICATIONS
FUZION 7260
*
UNDERMOUNT
DUAL MOTOR
72"
(1829 mm) L
60"
(1524 mm) W
21-1/2" ( 546 mm) H
244 lb
(111 kg)
1774 lb
(806 kg)/
59.1 lb/ft
2
(288 kg/m
2
)
16-3/4" (425 mm) A
12-1/16" (306 mm) B
Factory Installed
(BN60000 Heater)
Template
Provided
P/N
DD44000
Min - 110 U.S. gal
