45
CAUTION:
● Using screws with dimensions other than those specified in the above diagram may cause the projector to drop or
malfunction.
Dimensional Outline
Drawing
663
30
127
803 688
404
339
Center of gravity
30
827
449
677
M10 hole (x 12)
Tightening depth: 10 - 20
36
257.6
342
362
-
199
457
211
Center of lens
136
-
26
46
317
43.5
OPERATE
DVI 3 USB
LAN
RS-232C
STANDBY/ON
CONTROL
LAMP WARNING DVI 4
DVI 1
DVI 2
434
315
Ⅵ Top
Ⅵ Front
Ⅵ Side
Ⅵ Rear
(Unit: mm)
