INDEX
Front View
A Standby/On Button (STANDBY/ON A)
B Infrared Beam Receiving Window
C Disc tray
D Eject Button (
M) A pg. 9
E Record Button ( R) A pg. 35
F Stop Button ( o) A pg. 23
G Play Button ( I) A pg. 23
H Front Display Panel A pg. 13
I S-video Input Connector [S-VIDEO] A pg. 56
J Video/Audio Input Connectors [VIDEO/AUDIO (L(MONO)/
R)] A pg. 56
K DV Input connector [DV IN (A*)] A pg. 54
* i (i.Link) refers to the IEEE1394-1995 industry specification and
extensions thereof. The i logo is used for products compliant with the
i.Link standard.
L Programme Buttons (PR +/–) A pg. 35
STANDBY/ON RAM/RW
PR +
F-1
S-VIDEO VIDEO L(MONO) AUDIO R
DV DV IN
C B D E F G A
H I J K L
To access covered connectors,
press PUSH-OPEN to open the
cover.
PR +
PR-
PUSH-OPEN
