VM9410
18
DVD SETUP MENU
In “DVD Setup” mode, “LANGUAGE”, “VIDEO”, “AUDIO”,
“SURR SETUP”, and “RATING” (parental lock) are available
for setup. This operation can be performed using the remote
control or joystick controls.
Accessing the DVD Setup Screen
For system settings, press the DVD SETUP button (31) on
the remote control to enter the “DVD Setup” menu.
“LANGUAGE” is highlighted in green.
NOTE: Once the DVD setup is complete, the settings are
memorized. To return to the factory default settings,
press the RESET button (22) on the front panel.
Accessing a Menu
To access a menu (LANGUAGE, VIDEO, AUDIO, SURR
SET-UP, or RATING), press the direction buttons on the
joystick (16, 17, 18, 19) or remote control (14, 17, 18, 19, 22)
to highlight the desired menu in green.
Selecting a Feature for Adjustment
Once inside a menu, press the or buttons (14, 22) on
the remote control or the or buttons (18, 19) on the
joystick to select the feature to be adjusted.
Adjusting a Feature
1.
Enter the option field for the feature you want to adjust
by pressing the
button (18) on the remote or by
pressing the ENTER (joystick) button (20) on the unit. A
submenu appears in a second row with the selected
option highlighted in light blue.
2. Select a new value by pressing the or buttons (14,
22) on the remote control or the or buttons (18, 19)
on the joystick.
3. Confirm your selection by pressing the , , or
buttons (14, 17, 19) on the remote control, or the or
button (16, 17) on the joystick. The new value is
highlighted in light blue and setup is complete.
LANGUAGE Menu
If a DVD supports more than 1 Subtitle or Audio language, all
the languages are available for selection during playback. If
the selected language is not supported by the DVD, then the
default language is used. During playback, press the
SUBTITLE (9) or AUDIO (5) button on the remote control to
change the language directly. This will not effect the DVD
menu settings.
VIDEO Menu
NOTE: For standard discs not formatted for
“widescreen”, use of the 16:9 aspect ratio will result in
image distortion.
AUDIO Menu
The VM9410 has a built-in Pink Noise generator to help set
the relative speaker levels for multi-channel audio playback.
LANGUAGE VIDEO AUDIO
SURR SETUP RATING
DVD-Setup
Table 12: LANGUAGE Menu Features
Setting Options Function
Subtitle English Select the default language in which
you would like subtitles (if applicable) to
be displayed
Chinese
Auto
Off
Audio English Select the default language in which
you would like audio (when optional) to
be played
Chinese
DVD Menu English Select the default language in which
you would like the DVD menu (if appli-
cable) to be displayed
Chinese
Return to previous menu
Table 13: VIDEO Menu Features
Setting Options Function
TV Shape
(Aspect
Ratio) 4:3 PS With 16:9 display, the left and right sides
are cut off
4:3 LB With 16:9 display, the top and bottom are
cut off
16:9 Image is presented in wide view with a
16:9 aspect ratio
Angle
Mark On Angle indicator (if applicable) is shown
Off Angle indicator is not shown
Return to previous menu
Table 14: AUDIO Menu Features
Setting Options Function
Pink
Noise Off Stop output of pink noise
Left Left channel pink noise
Center Center channel pink noise
Right Right channel pink noise
Left Surr Left surround channel pink noise
Right Surr Right surround channel pink noise
Subwoofer Subwoofer pink noise
DRC Off Employ the Dynamic Range Control for
better playback for low volumes.
On
Surround
Mode Off
Surround I Use to decode surround effects from
analog or digital 2-channel down-
mixed sources.
Surround II Use to decode surround effects from
digital bit-stream movies.
SURR Matrix Apply matrixed effects to mono
sources.
SURR Movie Apply enhanced movie surround
effects.
SURR Music Apply surround music effects.
CNTR
CTRL 5ms Adjust the time difference between the
center and front speakers to create a
time delay between 1 and 5 millisec-
onds, producing a more accurate audio
effect.
4ms
3ms
2ms
1ms
0ms
