VM9410
11
OPERATING INSTRUCTIONS
Power On / Off
Press the /MUTE button (1) to turn the unit on. The buttons
on the front of the unit light up and “WELCOME” appears
briefly in the LCD panel (17), followed by the current mode
status. If the TFT screen is open, only the current mode
status is displayed. You can also turn on the unit by pressing
the OPEN button (2) and opening the TFT screen.
Press and hold the /MUTE button (1) on the front panel or
the POWER button (#) on the remote to power off the
unit.The monitor is drawn back into the main compartment
and the LCD screen displays “BYE-BYE”.
Audible Beep Confirmation
An audible beep tone confirms each function selection. The
beep tone cannot be disabled.
Mute
Press the /MUTE button (1) on the front panel or the MUTE
button (3) on the remote to mute the volume from the unit.
Press the MUTE button again to restore the volume. “MUTE”
is displayed on the LCD monitor. Adjusting the volume or
using any of the audio set-up features cancels the mute
function.
Playing Source Selection
Press the SRC/P.MODE button (15) on the front panel or the
SRC button (8) on the remote to change between available
playing sources in the following order: TUNER, DVD, CD
Changer, AUX IN or CAMERA (rear view video camera). The
playing mode is displayed on the TFT and LCD screens.
AUX IN Mode
An external peripheral device can be connected to this unit
via RCA output and “AUX-IN”.
CAMERA Mode
“CAMERA” mode is only available if the camera is connected
and during reverse driving. To install a rear view video
camera, connect the video input cable to the camera output
cable.
Volume Adjustment
To increase or decrease the volume level, turn the ROTARY
ENCODER (6) on the front panel or press the VOL+/ VOL-
buttons (15, 16) on remote control. When the volume level
reaches “0” or “40”, a beep sounds, indicating that the
adjustment limit has been reached. The volume ranges from
“0” to “40”. The LCD or TFT screen displays the volume level
for 3 seconds.
Audio Control Menu
The Audio Control feature allows you to easily adjust your
audio system to meet the acoustical characteristics of your
vehicle, which vary depending on the type of vehicle and its
measurements. To get the best possible sound quality from
your new system, be sure to adjust the settings for the
speakers as well. Proper setting of the Fader and Balance
boosts the effects of the cabin equalizer.
Accessing the Audio Control Menu
Press the VOL/LOC/DX knob (6) on the front panel once to
display the “AUDIO” menu.
Selecting an Audio Feature for Adjustment
Continuously press the VOL/LOC/DX knob (6) on the front
panel, or press the (
)/( ) buttons (14, 22) on the remote
control or the ( )/( ) buttons (18, 19) on the joystick to
select the audio feature to be adjusted.
Adjusting an Audio Feature
Rotate the VOL/LOC/DX knob (6), press the ( )/( )
buttons (17, 19) on the remote control, or press the ( )/( )
buttons (16, 17) on the joystick to adjust the selected feature
to the desired setting.
NOTE: The Bass and Treble levels are only adjustable
when EQ is set to “User” mode.
The Loud function compensates for deficiencies in sound
ranges at low levels. Loudness levels range from 1-4 or “off”.
When the Loud function is on, LOUD is displayed on the
screen.
Exiting the Audio Control Menu
Press and hold the VOL/LOC/DX knob (6) or stop making
adjustments for a few seconds to exit the audio control menu.
Six-Channel Audio Control
NOTE: Before adjusting the volume of any speaker,
please refer to “Surround Setup” on page 19.
Rear Zone
If a monitor is installed in the rear zone and connected to the
rear zone AV output, passengers in the back seat can control
the DVD output using the rear zone remote control. See
“Rear Zone Remote COntrol” on page 9 for instructions.
System Reset
To correct a system halt or other illegal operation, use the tip
of a pen to press the RESET button (22) located on the front
bottom-right corner of the unit. After a system reset, the unit
restores all factory default settings.
NOTE: If the unit is reset while a DVD is playing, the DVD
resumes play once the reset is complete.
Line Mute
If the “MUTE” wire is connected, audio output mutes when a
telephone call is received by the car phone or when verbal
navigation is performed.
Table 5: Audio Adjustments
Audio Function Adjustable Range
EQ User
Flat
Jazz
Pop
Classical
Treble -7 to +7
FADE -7 to +7
BAL -9 to +9
SUB.W -9 to +9
Loud Off, 1-4
Table 6: 6-Channel Audio Adjustments
Item Adjustable Range
Master Volume 00 to 40
Front Left Channel Volume -10 to +10
Front Right Channel Volume -10 to +10
Rear Left Channel Volume -10 to +10
Rear Right Channel Volume -10 to +10
Center Channel Volume -10 to +10
Subwoofer Volume -10 to +10
[RESET] Button
