Control elements and accessories
4
1 Filler funnel for pre-ground coffee 10 Cup platform
2 Cup tray 11 JURA Auto-Cappuccino Cleaner
3 Water tank with level indicator 12 Drawer with coffee grounds container
4 Overview of maintenance indicators 13 Height-adjustable coffee spout
5 CLARIS plus filter cartridge 14 Easy Cappuccino Frother with milk pipe
6 Hot water nozzle 15 Connector System © for removable nozzles
7 Measuring spoon for pre-ground coffee
16 Switch for water and milk preparation
8 JURA cleaning tablets 17 Bean container, aroma preservation cover
9 Drip tray
Control elements and accessories
1
2
3
4
5
6
7
8
17
16
15
14
13
12
10
9
Power switch and cable (see rear side)
Switch for setting fineness
of grind
11
Figure: IMPRESSA C5 platinum
