Specifications
■ Optical mechanism system
■
Electrical system
■ Input terminals
■
Output terminal
• Projection method D-ILA™ (Direct Drive Image Light Amplifier) method
(Reflective-type active-matrix method)
• D-ILA™ device 0.9" (2.3 cm) measured diagonally (1365 pixels × 1024 pixels) × 3
(Total number of pixels : 4,193,280)
• Projecting lens Electric-driven zoom of 1.5 ×
• Screen size 40" to 300" [recommended] to 521" [maximum] measured diagonally (*with aspect ratio: 4 : 3)
• Light-source lamp 420 W xenon lamp
• Color system NTSC, NTSC4.43, PAL, SECAM (Automatic switching / manual switching)
• Resolution 1365 dots × 1024 dots (S-XGA full resolution, during RGB input)
1000 TV lines (Horizontal resolution, aspect ratio 4 : 3, during video input)
• Scanning frequency Horizontal frequency : 15 kHz ~ 105 kHz
Vertical frequency
: 50 Hz ~ 100 Hz
[AV IN]
• Y/C 1-line, mini-DIN 4 pin × 1 (for S-video)
• VIDEO 1-line, BNC × 1 (for composite video)
[PC 1]
• R, G, B, H, V 1-line, D-sub 3-row 15 pin × 1 (for computer)
[PC 2]
1-line, BNC × 5 (for computer, DTV or video)
• Y, B-Y, R-Y Component (Y, B-Y, R-Y) signal
• Y, P B , P R DTV-format (Y, P B , P R ) signal
• R, B, G Analog RGB signal
• H/C s , V Horizontal (H) sync/composite (C S ) sync, Vertical (V) sync signal
[CONTROL]
• RS-232C 1-line, D-sub 9-pin × 1
* RS-232C-interface specified control terminal for controlling this projector with a personal
computer.
• REMOTE 1-line, stereo mini-jack × 1
* Remote terminal for connecting an infrared remote sensor extension unit, etc.
• PC OUT 1-line, D-sub 3-row 15-pin × 1 (output for display monitor)
