DLA-G150HTE 1-24
No.51847
44
Menu Operations
Changing the Color System (Video Menu Mode Only)
This function is available only in Video menu mode.
The menu is only displayed when there is a signal for the AV IN (Y/C and VIDEO) terminal, and not displayed when there is a
signal for the PC2 terminal.
Normally, use the color system in AUTO. If operation in AUTO is unstable, such as color not being shown, set to a dedicated
color system in accordance with the color system of the video signal being input.
1 Press the MENU button.
The main menu appears on the screen.
2 Select “Setting” with the cursor button 5 or ∞ ∞ ∞ ∞, and press 3 3 3 3 or the ENTER button.
The “Setting 1” submenu appears on the screen.
3 Select “Decoder” with the cursor button 5 or ∞ ∞ ∞ ∞, and press the ENTER button.
The “Decoder” submenu appears on the screen.
Video submenus
4 Set the color system with the cursor button 5 or ∞ ∞ ∞ ∞.
AUTO: Normally, set to “AUTO”. (Factory set value)
The color system of a video signal being input is automatically identified and displayed in [ ].
In [ ], B/W (Black & White), NTSC, NTSC4.43, PAL or SECAM will be displayed. (It is not always displayed.)
For example, AUTO [ NTSC ] shows that the NTSC signal is being received.
NTSC: Dedicated to NTSC.
NTSC4.43: Dedicated to NTSC4.43.
PAL:
Dedicated to PAL.
SECAM: Dedicated to SECAM.
5 Press the EXIT button to return to the previous menu or press the MENU button to
exit the menu mode.
Setting 1
Position
Tone
Aspect change
Decoder
Setting 2 ENTER
ENTER
ENTER
TV
4:3
Cinema
16:9
Decoder
AUTO [ NTSC ]
NTSC
NTSC4.43
PAL
SECAM
ENTER
EXIT
43
Menu Operations
ENGLISH
DEUTSH
FRAN
ÇAIS
ITALIANO
ESPAÑOL
Basic Menu Operation (Cont.)
■ Basic Button Functions in the Menu Mode
■ Remote control unit ■ Projector
■ Video menu mode
■ PC menu mode
Button Function
MENU Enters the main menu or exits the menu mode.
Cursor button 5 / ∞ Selects an item in the menu. Pressing ∞ or 5 will scroll the item in the menu.
Cursor button 2 / 3 Sets or adjusts the value.
PRESET If pressed while the keystone setting submenu is displayed, the value is set to “0”.
EXIT Returns to the previous menu.
ENTER Used to enter the submenu from the main menu.
Used to enter the next submenu if “ENTER” is displayed in the selected item.
QUICK ALIGN.
PC1 PC2 Y/C VIDEO
HIDE
PRESET
ENTER EXIT
MENU
FREEZE SCREEN
OPERATE
DIGITAL ZOOM ZOOM FOCUS
W
W
S
T
W
T
RM-M150 REMOTE CONTROL UNIT
SCREEN
KEYSTONE
W
S
MENU button
ENTER button
Cursor buttons
5/∞ / 2/3
PRESET button
EXIT button
LAMP TEMP STAND BY
HIDE
PC
VIDEO
MENU
KEYSTONE
PRESET
EXIT ENTER
OPERATE
MENU
button
ENTER
button
Cursor buttons
5/∞ / 2/3
PRESET
button
EXIT
button
Menu
Image adj.
Setting
Color temp.
Options
Language
Information
Brightness
Contrast
Sharpness
Color
Tint
All reset
Image adj.
Brightness
Contrast
Sharpness
Color
Tint
All reset
12
12
1
12
12
ENTER
Video main menu Video submenu
Press 5/∞ to select an item.
Press 2/3 to set or adjust the value.
Press 5/∞ to select an item.
3 or
ENTER
EXIT
Menu
Image adj.
Setting
Color temp.
Options
Language
Information
Brightness
Contrast
Sharpness
All reset
Image adj.
Brightness
Contrast
Sharpness
All reset
12
12
ENTER
1 2 3 4 5
PC main menu PC submenu
Press 5/∞ to select an item.
Press 2/3 to set or adjust the value.
Press 5/∞ to select an item.
3 or
ENTER
EXIT
