8
t
i
t
i
Grip Adjustment
1) Separate the Velcro strip.
2) Pass your right hand through the loop and grasp
the grip.
3) Adjust so that your thumb and fingers can easily
operate the Recording Start/Stop Button
!
and
Power Zoom Lever
3
. Refasten the Velcro strip.
Loading/Unloading A Cassette
1) Open the LCD monitor fully*. Slide EJECT
t
until the cassette holder opens. Do not use force
to open.
2) Insert or remove a cassette. When inserting,
make sure the label is facing outward.
q
appears when a cassette is loaded.
3) Press the Close button
i
to close the cassette
holder until it locks into place. Close the LCD
monitor*.
• Closing the LCD monitor while the cassette holder is
still open may cause damage to the LCD monitor*.
• Make sure the erase protection tab is in the position
that allows recording. If not, slide the tab. Some
cassettes have removable tabs. If the tab has been
removed, cover the hole with adhesive tape.
• The cassette holder cannot be opened while the
camcorder is in the record mode or detached from
the power source.
* Applicable models only.
Tripod Mounting
Align the screw and camera direction stud on the
tripod with the tripod mounting socket
W
. Then
tighten the screw.
CAUTION
When using a tripod, be
sure to open and extend
its legs fully to stabilise
the camcorder. To
prevent damage to the
unit caused by falling
over, do not use a
small-sized tripod.
Shoulder Strap Attachment
Thread the strap through the eyelet
y
, then fold it
back and thread it through the buckle. Repeat the
procedure to attach the other end of the strap to
the other eyelet
y
, making sure the strap is not
twisted. Adjust the length.
Viewfinder Adjustment
1) Set the Power Switch
@
to “ ” or “ ”.
2) Turn the Dioptre Adjustment Control
o
until the
indications in the viewfinder are clearly focused.
PAUSE
180
°
180
°
Cassette holder
Gear
Turn to
take up
slack.
y
3
!
Cassette
holder
Erase
Protection tab
