PANEL1173-841 User’s Manual
Driver Installation 62
4.2 Touch Screen
4.2.1 Specification
Touch Screen 5-wire Analog Resistive type
Touch Screen Controller DMC9000 (10-bit A/D converter inside)
Communications RS-232
Baud Rate 19200 and 9600 baud selection
Resolution 2048 x 2048
Mode Selection PnP or non-PnP
Power Input 5V DC
Power Consumption 12V: 23mA+ i where (i = v/touch screen sheet
R)
5V: 20mA+ i where (i = v/touch screen sheet
R)
Mechanical Size 60(L) x 26(W) x 8.3(H)mm
Portrait Support 90o to 270o screen rotation
Others Touch activate indication LED on board
