Intel System Board G4H875-N User Manual
Page 41
41
2
Hardware Installation
2.5.5 RJ45 LAN Port
G4H875-N is equipped with 2 onboard RJ45 LAN ports. LAN 1
which is controlled by the Intel 82551QM chip is at location CN6
and LAN 2 which is controlled by the Intel Gigabit 82547EI chip is
at location CN5.
G4H875-C and G4H875-B are each equipped with the LAN 1
port only.
LAN allows the system board to connect to a local area network
by means of a network hub.
BIOS Setting
Enable or disable the Gigabit LAN in the Integrated Peripherals
submenu (“Onboard Device” section) of the BIOS. Refer to
chapter 3 for more information.
Driver Installation
Install the “Intel LAN Drivers”. Refer to chapter 4 for more infor-
mation.
"
"
LAN 2
LAN 1
G4H875-N only
2
1
O
N
