INSTALLATIONS
AR-B1760 User’s Manual
5
Installations
This section provides information on how to use the jumpers and
connectors on the AR-B1760 in order to set up a workable system. The
topics covered are:
Installing the CPU ............................................................... 6
Installing the Memory ......................................................... 7
Setting the Jumpers ............................................................. 8
Connectors on AR-B1760 ................................................. 14
Watchdog Timer Configuration ........................................ 26
Digital I/O Sample Code ................................................... 29
