INSTALLATIONS
6 AR-B1760 User’s Manual
Installing the CPU
The AR-B1760 embedded board supports a Socket 479 processor socket
for Intel
® Pentium ® M or Celeron ® M processors.
The processor socket comes with a screw to secure the processor. As
shown in the left picture below, loosen the screw first before inserting
the processor. Place the processor into the socket by making sure the
notch on the corner of the CPU corresponds with the notch on the inside
of the socket. Once the processor has slide into the socket, fasten the
screw. Refer to the figures below.
After you have installed the processor into the socket, check if the
jumpers for the CPU type and speed are correct.
