Intel SR6850HW4 User Manual
Page 84
SCSI Backplane Board Intel® Server Platform SR6850HW4 TPS
Revision
1.0
Intel order number D23151-001
72
3.3V REGULATOR
SCSI BUS A SAF-TE
CONTROLLER
SCSI BUS B SAF-TE
CONTROLLER
PLD
SCSI BUS B SAF-TE
CONTROLLER
FLASH MEMORY
SCSI BUS A SAF-TE
CONTROLLER
FLASH MEMORY
10 MHZ
OSCILLATOR
SCSI BUS A
TERMINATORS (2)
SCSI BUS B
TERMINATORS (2)
5V D2D
CONTROLLER
FRU
TEMP SENSE 1
TEMP SENSE 1
TAPE BAY POWER
CONNECTOR
POWER DISTRIBUTION
BOARD CONNECTOR
USB HUB
1.8V REGULATOR
Figure 30. SCSI Backplane Board Board Component Placement (Secondary Side)
