Power Supply Intel® Server Platform SR6850HW4 TPS
Revision 1.0
Intel order number D23151-001
54
5.2 Power Supply Output Interface
5.2.1 Blade Connector
The power supply output power and control signals interface to the system Power Distribution
Board through an FCI PowerBlade* right-angle connector.
Table 29. PowerBlade Pin Assignment
P1 Pin Signal Name Amps per pin
PB RH1 +12V return 26
PB RH2 +12V return 26
PB RH3 +12V return 26
PB RH4 +12V return 26
PB RH5 +12V return 26
PB RH6 +12V 26
PB RH7 +12V 26
PB RH8 +12V 26
PB RH9 +12V 26
PB RH10 +12V 26
A1 PS_KILL
A2 +12V current share
A3 Return
A4 +3.3V
stby
A5 PS A0
A6 +3.3V
stby
B1 Return
B2 Not used
B3 Return
B4 +3.3V
stby
B5 SDA
B6 -PS_ON
C1 Return
C2 Not used
C3 Return
C4 +3.3V
stby
C5 SCL
C6 VIN_GOOD
D1 -PS_Present
D2 +12V_Sense
D3 +12V_Rtn_Sense
D4 +3.3V
stby
D5 S_INT(Alert)
FCI Powerblade* 51721-
10002410AA or approved
equivalent
Mates to FCI 51741-
10002410CC on Power
Distribution Board
D6 POK
