Intel SR6850HW4 User Manual
Page 40
Server System Chassis and Assemblies
Intel® Server Platform SR6850HW4 TPS
Revision
1.0
Intel order number D23151-001
28
Figure 11. Hot-Swap Hard Drive Carrier
3.5.2
Optical Drive Carrier
The optical drive is installed in a sheet metal bracket. The SATA-to-IDE Converter Board is
plugged into the IDE connector at the back of the optical device. This assembly is then installed
into the chassis.
Figure 12. Optical Drive Carrier with SATA-to-IDE Converter Board
Latch
LED
Latch
LED
