Block diagram – Intel GA-EQ45M-S2 User Manual
Page 8
- 8 -
Block Diagram
BIOS
CPU CLK+/-
(333/266/200 MHz)
LGA775
Processor
Intel
®
Q45
LPC BUS
Line-Out
MIC
CODEC
Line-In
SPDIF In
SPDIF Out
Side Speaker Out
Center/Subwoofer Speaker Out
Surround Speaker Out
PCI Bus
Floppy
Host
Interface
PCI Express Bus
GMCH CLK
(333/266/200 MHz)
PS/2 KB/Mouse
IT8720
Intel
®
ICH10DO
1 PCI Express x1
PCIe CLK
(100 MHz)
x1
DDR2 800/667 MHz
Dual Channel Memory
12 USB Ports
6 SATA 3Gb/s
2 COM Ports
DVI
Intel
82567LM
LAN
RJ45
GLCI
x1
1 PCI Express x4
x4
2 PCI
ATA-133/100/66/33
IDE Channel
IT8213
D-Sub
TPM
