Ga-eq45m-s2 motherboard layout, Ga-eq45m-s2 – Intel GA-EQ45M-S2 User Manual
Page 7
- 7 -
GA-EQ45M-S2 Motherboard Layout
KB_MS
LGA775
ATX
GA-EQ45M-S2
USB
LAN
F_AUDIO
AUDIO
IT8720
IDE
DDR2_1
ATX_12V_2X
R_USB
CPU_FAN
Intel
®
Q45
MFG
PHASE LED
Intel
®
ICH10DO
1_BIOS
CD_IN
PCI1
BAT
Intel 82567LM
PCI2
SYS_FAN
DVI
SPDIF_I
DEBUG PORT
FDD
F_USB2
F_USB1
CODEC
SPDIF_O
DDR2_2
DDR2_3
DDR2_4
CLR_CMOS
PCIEX4
F_PANEL
VGA
2_BIOS
PCIEX1
COMA
IT8213
PWR_LED
CI
COMB
TPM IC
F_USB3
SATA2_0 SATA2_1
SATA2_2 SATA2_3
SATA2_4 SATA2_5
ACPI_LED
(S0/1/3/4/5_LED)
LPT
