AR-B1890 User’s Manual 39
PnP / PCI Configurations
Phoenix – AwardBIOS CMOS Setup Utility
PnP/PCI Configurations
Item Help Init Display First [ PCI Slot ]
Reset Configuration Data [ Disabled ]
Resources Controlled By [ Auto(ESCD) ]
IRQ Resources Press Enter
DMA Resources Press Enter
PCI/VGA Palette Snoop [ Disabled ]
** PCI Express relative items **
Maximum Payload Size [ 4096 ]
Menu Level >
Default is Disabled.
Select Enabled to reset
Extended System
Configuration Data
(ESCD) when you exit
Setup if you have
installed a new add-on
and the system
reconfiguration has
caused such a serious
conflict that the OS
cannot boot
↑↓→←:Move Enter:Select ＋/－/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Init Display First The default setting is PCI card.
Reset Configuration Data This option allows you to determine whether to
reset the configuration data or not.
Resources Controlled By This PnP BIOS can configure all of the boot and
compatible devices automatically with use a
PnP operating system.
PCI/VGA Palette Snoop
Enabled PCI/VGA can work with MPEG ISA/VESA VGA
card.
Disabled
PCI/VGA cannot work with MPEG ISA/VESA
VGA card.
Maximum Payload Size The default is 4096.
