AR-B1890 User’s Manual

19

DVOB Connector ( CN7 )

Pin Assignment

Pin Assignment

1 5V

2 3.3V

3 SDVOB_INT#

4 SDVOB_INT

5 2.5V

6 GND

7 SDVO_FLDSTALL#

8 SDVO_FLDSTALL

9 GND

10 GND

11 SDVOB_RED#

12 SDVOB_RED

13 GND

14 GND

15 SDVOB_GREEN# 16 SDVOB_GREEN

17 GND

18 GND

19 SDVOB_BLUE#

20 SDVOB_BLUE

21 GND

22 GND

23 SDVOB_CLK#

24 SDVOB_CLK

25 GND

26 GND

27

SDVOCTRL_CLK

28

N / C

29

SDVOCTRL_DATA

30

N / C

31 GND

32 GND

33

SDVOB_RST#

34

N / C
