AR-B1890 User’s Manual 20
LVDS Connector ( CN8 )
Pin Assignment Pin Assignment
1 BKL _ EN 2 BKL _ CTL
3 LVDS _ VCC 4 GND
5 LVDS _ CH1 _ CLK- 6 LVDS _ CH1 _ CLK+
7 LVDS _ VCC 8 GND
9 LVDS _ CH1 _ DATA0- 10 LVDS _ CH1 _ DATA0+
11 LVDS _ CH1 _ DATA1- 12 LVDS _ CH1 _ DATA1+
13 LVDS _ CH1 _ DATA2- 14 LVDS _ CH1 _ DATA2+
15 N / C 16 N / C
17 N / C 18 N / C
19 LVDS _ CH2 _ DATA0- 20 LVDS _ CH2 _ DATA0+
21 LVDS _ CH2 _ DATA1- 22 LVDS _ CH2 _ DATA1+
23 LVDS _ CH2 _ DATA2- 24 LVDS _ CH2 _ DATA2+
25 LVDS_DDCPDATA 26 LVDS_DDCPCLK
27 LVDS _ VCC 28 GND
29 LVDS _ CH2 _ CLK- 30 LVDS _ CH2 _ CLK+
ATX Power Connector ( CN9 )
Pin Assignment Pin Assignment
1 3.3V 2 3.3V
3 GND 4 5V
5 GND 6 5V
7 GND 8 N / C
9 5VSB 10 12V
11 3.3V 12 -12V
13 GND 14 PSON
15 GND 16 GND
17 GND 18 -5V
19 5V 20 5V
