AR-B1890 User’s Manual

15

Jumpers Setting

OPEN 1 - 2 - 3 SHORT 1 - 2 SHORT 2 - 3

□ ○ ○ ■ ● ○ □ ● ●

1 2 3 1 2 3 1 2 3

LVDS Panel Voltage Selection ( JP3 )

5V 3.3V

1 □ ○ 2 2 ● ● 3

Clear CMOS Selection ( JP5 )

Protected Clear CMOS

1 ■ ● 2 2 ○ ○ 3
