Integrated Peripherals
Phoenix – AwardBIOS CMOS Setup Utility
Integrated Peripherals
Item Help OnChip IDE Device [ Press Enter ]
Onboard Device [ Press Enter ]
Super IO Device [ Press Enter ]
Watch Dog Timer Select [ Disabled ]
Onboard Serial Port 5 [ 4F8 ]
Serial Port 5 Use IRQ [ IRQ5 ]
Onboard Serial Port 6 [ 4E8 ]
Serial Port 5 Use IRQ [ IRQ7 ]
Menu Level >
↑↓→←:Move Enter:Select ＋/－/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Phoenix – AwardBIOS CMOS Setup Utility
OnChip IDE Device
Item Help IDE HDD Block Mode [ Enabled ]
IDE DMA transfer access [ Enabled ]
On-Chip Primary PCI IDE [ Enabled ]
IDE Primary Master PIO [ Auto ]
IDE Primary Slave PIO [ Auto ]
IDE Primary Master UDMA [ Auto ]
IDE Primary Slave UDMA [ Auto ]
*** On-Chip Serial ATA Setting ***
On-Chip Serial ATA [ Auto ]
PATA IDE Mode SECONDARY
SATA Port P0,P2 IS Primary
Menu Level >
↑↓→←:Move Enter:Select ＋/－/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
IDE HDD Block Mode This option allows your Hard disk controller to
use the fast block mode to transfer data to and
from your Hard disk drive.
IDE DMA transfer access The default is Enabled.
