AR-B1890 User’s Manual 38
Video Off Method
V/H SYNC+Blank Blank the screen and turn off vertical and
horizontal scanning.
DPMS Allows BIOS to control the video display.
Blank Screen Writes blanks to the video buffer.
Video Off In Suspend Select the Video Off in Suspend mode.
Suspend Type The default is Stop Grant.
MODEM Use IRQ
This option allows you to set the IRQ by Modem.
Suspend Mode
After the set time of system inactivity, all devices
except CPU will be shut off.
HDD Power Down After the set time of system inactivity, the Hard
disk drive will be power down while all other
devices remain active.
Soft-Off by PWR-BTTN
Instant-Off Press power button then Power Off instantly.
Delay 4 Sec. Press power button 4 seconds to Power Off.
Enter suspend if button is pressed less than 4
seconds.
Wake-Up by PCI card The default is Enabled.
Power On by Ring This field enable or disable the power on of the
system through the modem connected to
the serial port or LAN.
Resume by Alarm This field enable or disable the resumption of the
system operation.
Reload Global Timer Events This field their default setting are:
Primary IDE 0 Disabled
Primary IDE 1 Disabled
Secondary IDE 0 Disabled
Secondary IDE 1 Disabled
FDD, COM, LPT, Port Disabled
PCI PIRQ(A-D)# Disabled
