Technical Features

Warning Messages

If no pictures appears on the screen, one of the following
messages appears on the screen.

If NO INPUT SIGNAL appears on the screen

1 The selected connector

This message shows the currently selected connector
(INPUT 1 or INPUT 2).

2 The input signal condition

NO INPUT SINGAL

This indicates that no signal is input, or that no signal is
input from the selected connector.

3 The remedies

One or more of the following messages may appear on
the screen.
• If ACTIVATE USING PC appears on the screen, try

pressing any key on the computer, and confirm that
your computer’s graphic board is completely seated
in the correct bus slot.

• If CHECK INPUT SELECTOR appears on the screen,

try changing the input signal (page 5).

• If CHECK SIGNAL CABLE appears on the screen,

check that the monitor is correctly connected to the
computer (page 4).

Additional Information

If OUT OF SCAN RANGE appears on the screen

1 The selected connector and the

frequencies of the current input signal

This message shows the currently selected connector
(INPUT 1 or INPUT 2). If the monitor recognizes the
frequencies of the current input signal, the horizontal
and vertical frequencies are also displayed.

2 The input signal condition

OUT OF SCAN RANGE

This indicates that the input signal is not supported by
the monitor’s specifications.

3 The remedies

CHANGE SIGNAL TIMING appears on the screen. If
you are replacing an old monitor with this monitor,
reconnect the old monitor. Then adjust the computer’s
graphic board to that the horizontal frequency is
between 30 - 121 kHz, and the vertical frequency is
between 48 - 160 Hz.

For more information, see “Troubleshooting” on page 18.

MON I TOR

I S WORK I NG

I NPUT

1 :

I NPUT

S I GNA L

ACT I VA T E US I NG PC
CHECK

I NPUT SE L ECT R

CHECK S I GNA L CAB L E

WH I T E

RED
GREEN
B L UE

I NFORMA T I ON

MON I TOR

I S WORK I NG

I NPUT

1 : 1 3 0 . 0 k H z /

OUT OF SCAN RANGE

CHANGE S I GNA L

T I M I NG

WH I T E

RED
GREEN
B L UE

I NFORMA T I ON
